SpiroTrap -Steel -Magnet -F(PN16)

A steel dirt separator with magnet for standard flow rate (1.5 m/s) with a DN50 - DN300 PN16 flange connection

Magnet

The benefits of the BE-FM SpiroTrap dirt separators with magnet

  • Very small particles, from 5 μm (= 0.005 mm) are separated and removed
  • Integrated magnet for extra protection and removal of magnetite
  • Dirt can be drained while the system is in operation
  • No shut-off valves or bypass required
  • Applicable with 50/50 Ethylene Glycol / Water (Volume)
  • Constant low pressure drop
  • Maintenance only takes a few seconds
  • No unnecessary downtime
  • PN16 flange connection
  • Connection diameters from DN50 to DN 300, larger connection diameters on request

Product variants

Select the desired connection below and get all (technical) product data!

Article number BE050FM
Product type SpiroTrap -DN50 -Magnet -Flange

The optimal position of a SpiroTrap dirt separator

To optimally protect your heating or cooling system, the correct placement of a dirt separator is essential. A dirt separator is preferably installed at the point where the system water enters the heating or cooling unit, usually in the return line.

Why on the return line?

  • Here, the water flows back to the (sensitive) system components, such as pumps, heat exchangers and valves.
  • Trapping debris at this point will prevent it from causing damage to these crucial parts.
  • This not only improves the performance and lifespan of your system, but also reduces the risk of breakdowns and maintenance costs.

With a strategically placed dirt separator from Spirotech, your system stays clean, efficient and protected from contamination, even under the most demanding conditions. This way you ensure a problem-free and durable system.

Positioning the dirt separator in your system
